| Oxygen
Saturation and Pulse Rate |
| Flow Rate |
0.1 to 199 ml / hr |
| Accurracy |
±2% |
| Display |
LCD Display; Running Mode Message Display |
| Totalizer |
Indication for total volume infused up to 999 ml |
| Volume Limit |
Limit for total volume to be infused 0.1 ml to 999 ml |
| Resolution |
0.1 ml / hr for Display up to 99.9 ml.
1 ml for Display 100 to 999 ml. |
| Syringe Size |
Accepts syringe from 10 ml to 60 ml precalibrated for 4 different makes
and equivalent AutoSyringe Detect |
| Bolus |
Two modes: On the Bolus
Programmed Bolus |
| Purge Function |
Empty syringe on completion of Infusion |
| Drug Library |
Programmed 40+ Drug Library |
| Memory |
Built-in memory for Start Function on Stop Infusion |
| Dimensions (L x W x H) |
245 x 160 x 120 mm |
| Weight |
approx. 3 Kg |
| Body Construction |
Splash Proof and Tropicalized |
| Occlusion Pressure |
Three level setting with automatic pressure release |
| Alarms |
Syringe Empty, Infusion Complete, Occlusion, Low Battery,
Bolus Complete |
| Power Supply |
170 – 240 VAC, ±15%, 50 – 60 Hz |
| Battery Back-up |
In-built 6V rechargeable, maintenance-free battery provides back-up
for approx. 6 hrs @ 10 ml / hr
|
| Humidity |
Up to 95% non-condensation |
| Operating Temperature |
5 – 45º Celsius tropicalized |
